IP Input Edge QAM modulator

The SKD180X is a 1RU rack-mountable compact headend enables you to receive the content from IP network and modulate the programs into digital cable channels for distribution over coax. Three hot-swappable modular allows operators to scale service as demand increased. This product can help operators to rollout the video service by the existing cable system quickly, efficiently and easily.

  • Brand:

    SOUKA
  • Item NO.:

    SKD180X
  • Order(MOQ):

    1
  • Payment:

    Ex-work
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Product Detail

SKD180X

IP TO QAM EDGE MODULATOR

FEATURES

1. Offers 12 non-adjacent output channels organized as 3 independent modular of 4 channels

2. Support unicast and multicast over UDP and RTP

3. Automatically generate PSI/ SI table

4. Support PID remapping

5. Easy configuration with built-in Web UI

6. Automatically transfers the configuration to a replaced modular in the same slot

SPECIFICATION

GbE INPUT

Input Slot Number

3

Input Connector

1 RJ*45 input per card

Transport Protocol

UDP, RTP

Addressing

Unicast, Multicast

MPEG Transport

SPTS

MODULATION

ATSC

Standard

ATSC A/53 (6M)

Constellation

8VSB

MER

36 dB

DVB-C J.83A

Standard

Annex A (8M)

Constellation

64QAM, 256QAM

MER

36 dB

Symbol Rate

5 ~ 6.952 Ms/s

DVB-C J.83B

Standard

Annex B (6M)

Constellation

64QAM, 256QAM

Symbol Rate

5.067 / 5.360 Ms/s

MER

36 dB

Cable Standard

HRC, IRC or STD

DVB-T

Standard

DVB-T COFDM (6M, 7M, 8M)

Constellation

16QAM, 64QAM

MER

36 dB

Transmission Mode

2K, 4K, 8K

Coderate / Guard Interval

1/2, 2/3, 3/4, 5/6, 7/8  !  1/32, 1/16, 1/8, 1/4

Symbol Rate

6000 / 7000 / 8000 KS/s

DTMB

Standard

GB20600-2006 (8M)

Constellation

QPSK,4QAM-NR, 16QAM, 32QAM, 64QAM

MER

36 dB

Interleaving Mode

INTLV_NONE, INTLV_240, INTLV_720

Rate Code / Carrier Type

0.4, 0.6, 0.8   /  Multi-carrier, Single-carrier

Sync Frame / PN Phase

420, 595, 945,  /  Variable, Constant

OUTPUT

RF

Connector

F female connector @ 75 Ohm

Output Level

45dBmV per modular

37dBmV combined, 12 channels

Output Frequency Range

50 ~ 1000MHz

Out-band Rejection

60dB

SYSTEM

Management

Control Keys; NMS;

Management Port

RJ-45 (100M)

Language

English

Upgrade

NMS

GENERAL

Power Supply

AC 80 ~ 264V

Power Consumption

MAX. Current

1.8A/115VAC, 1A/230VAC

Dimensions

480*366*44MM
