The SKD7150P is a compact DVB-S/S2 to IP Gateway designed for small-scale IPTV systems. It supports 2 input modules with CI slots for satellite signal reception and decryption, and delivers IP output via Gigabit Ethernet in UDP/RTP format (MPTS with 8 IPs or SPTS with 256 IPs). With web-based management and cloud support, it is suitable for hotels, schools, and other commercial applications.
PCMCIA Satellite Input IP Output Gateway Ci Cam Card Tuner to IP Encoder Streamer
1. A single device supports up to 2 input modules.
2. Supports 2 or 4 DVBS-S2 input with CI Slot, independent PCMCIA card decryption.
3. Supports PID remapping, PSI/SI information editing and insertion.
4. Supports optional MPTS or SPTS output. For MPTS, the maximum supported is 8 IP addresses; for SPTS, the maximum supported is 256 IP addresses.
5. 1 Gigabit port and 1 management port.
6. Operated through PC (WEB), the device supports cloud management.
| Brand | SOUKA |
|---|---|
| Item NO. | SKD7150P |
| Order(MOQ) | 1 |
| Payment | EX-WORK |
| Product Origin | China |
| Color | Black |
| Shipping Port | Shenzhen |
| Lead Time | 3 working days |
| Host performance parameters | |
| Size | 318 (L)*260 (W)*44 (H)mm |
| Installation form | 1U 19 inch chassis; Support Desktop, Rack-mounted and wall-mounted |
| Working temperature, humidity | -10℃-45℃、40%-70% |
| Storage temperature and humidity | -40℃-70℃、40%-95% |
| Power parameters | |
| Supply voltage | DC 12 V |
| Maximum current | 7000 mA |
| DVB-S/S2 with CI Slot input module parameter | |
| Total number of slots | 2 |
| Each slot can support | 2 CI Slot |
| 2 CAM slots | |
| IP output parameter | |
| IP output connector | 1 Gigabit RJ45 network port |
| Output format | Supports UDP/RTP protocol output; supports SPTS/MPTS stream processing; output IP Stream in MPTS with 8 IP Address or SPTS with 256 IP address |
Engineered with flexible hardware frontends, SOUKA IPTV Streamers ingest diverse broadcast feeds—including multi-channel HDMI (HDCP compliant), HD-SDI, and DVB-S2/T2/C Tuners. Dedicated onboard ASIC packetization engines encapsulate incoming media into enterprise IP transport streams (UDP/RTP, SPTS/MPTS, HLS, RTSP, RTMP, and SRT), enabling unified digital video distribution across local hospitality LANs and enterprise WAN architectures without quality loss.
Powered by dedicated FPGA/ASIC hardware compression and multiplexing engines, SOUKA streamers execute real-time H.264 (AVC) and H.265 (HEVC) stream processing with ultra-low transmission latency (<200ms). Packaged in a compact 1U rackmount form factor (supporting 8, 16, or 24 channels), the system guarantees zero packet dropping, ultra-low jitter, and continuous carrier-grade stability under full-load 24/7 commercial operation.
SOUKA streamers provide robust network protection with native support for IGMP v2/v3 multicast protocols and Layer 3 VLAN slicing. By confining high-bandwidth transport streams within dedicated IPTV subnets, the hardware completely eliminates multicast packet flooding into guest Wi-Fi or property management networks. Integrators can remotely manage PID remapping, stream bitrate capping, and channel routing via an embedded Web GUI and SNMP network management console.
