Single HD to RF MEPG2 ATSC/QAM Modulator

The SKD2618 is a professional quality digital modulator, designed in 2RU dies-cast case. It can distribute video in nearly any resolution from an unencrypted HD source up to 1080P into a private television channels.

  • Brand:

    SOUKA
  • Item NO.:

    SKD2618
  • Order(MOQ):

    16
  • Payment:

    Ex-work
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Product Detail

SKD2618

MPEG 2 ENCODER MODULATOR

FEATURES:

1. Support MPEG 2 FHD video encoding for North America market

2. Support ATSC/J.83B modulation, selected via front panel control

3. Robust die-cast case

4. Support STD,IRC and HRC offsets

5. Operated and control via NMS

SPECIFICATION:

ENCODING

INPUT CONNECTOR

HDMI 1.4

VIDEO

Encoding

MPEG 2

Input Resolution

1920*1080_60P; 1920*1080_50P; 1920*1080_60i;

1920*1080_50i; 1280*720_60P; 1280*720_50P

Bitrate

1 ~ 19.5 Mbps

AUDIO

Encoding

MPEG 1 Layer II, Dolby AC3 (DDCE Mode)

Sample Rate

48KHz/ 44.1KHz/ 32KHz

Bitrate

384kbps

MODULATION

J.83B

Constellation

64 / 256 QAM

MER

36 dB

Symbol Rate

5.056941 & 5.360537 Msps

Output Frequency

50 ~ 999.9 MHz

Output Level

30dBmV (0~20dB adjust range)

Cable Standard

HRC, IRC or STD

ATSC

Constellation

8VBS

MER

32dB

Output Level

30dBmV (0~20dB adjust range)

Output Frequency

50 ~ 999.9 MHz

General

Power Header

3PIN: GND,12V & NC

Input Voltage

DC12V

Current

680mA
