SKD50 Series AHD Signal Extender

The SKD50 Series AHD Signal Extender is a high-definition image transmission device designed by SOUKA for monitoring. It mainly provides long-distance transmission for AHD high-definition video signals.

  • Brand:

    SOUKA
  • Item NO.:

    SKD50
  • Order(MOQ):

    1
  • Payment:

    Ex-work
  • Product Origin:

    China
  • Color:

    Black
  • Shipping Port:

    Shenzhen
  • Product Detail



The SKD50 Series AHD Signal Extender is a high-definition image transmission device designed by SOUKA for monitoring. It mainly provides long-distance transmission for AHD high-definition video signals. This product can support 2 megapixel high-definition video and analog signals, which can be suitable for all kinds of monitoring fields.




Features:

Includes an AHD variable channel modulation module and an AHD variable channel demodulation module

2 megapixel high-quality image analog signals

Long transmission distance and the adjustable channel can mix 99 different channels without interfering with each other




Technical Parameters:


HD input

Port

HD 1.4a

Resolution

1920*1080_60P,1920*1080_50P;1920*1080_60i, 1920*1080_50i;1280*720_60p, 1280*720_50P

AHD video input

Port

BNC TYPE 75Ω

Resolution

FORMAT

HZ

H*V

FSC(MHz)

NTSC-M,J

NTSC-4.43

59.94

720*240,960*240

3.579545

59.94

720*240,960*240

4.4331875

PAL-B,D,G,H,I

PAL-M

50

720*288,960*288

4.4331875

59.94

720*240,960*240

3.57561149

PAL-NC

50

720*288,960*288

3.58205625

PAL-60

60

720*240,960*240

4.433619

Resolution

AHD_1080_30P

30

1920*1080

Flexible

AHD_1080_25P

25

1920*1080

Flexible

AHD_720_60P

60

1280*720

Flexible

AHD_720_50P

50

1280*720

Flexible

AHD_720_30P

30

1280*720

Flexible

AHD_720_25P

25

1280*720

Flexible

Power supply

DC12V/1A

RF output port

BNC TYPE 75Ω

RF output test point

-20dB

Output Power

100dBuV

Output channel range

Variable channel, select one from 1-99 channel

Output channel display

2-digit LED

Audio input port

RCA

Audio maximum input electrical level

1.5Vp-p

485 communication port

SC3.81-21R-3P



AHD RX / TX

RF input port

BNC TYPE 75Ω

RF input power requirements

36-105dBuV

Input channel range

Variable channel, select one from 1-99 channel

Input channel display

2-digit LED



Power supply

DC12V/1A

AHD output port

BNC TYPE 75Ω

Audio output port

RCA

485 communication port

SC3.81-21R-3P



Physical parameters

Operating temperature, humidity

-10-4540%-70%
